Fabric Printing
Main Features:
Print on socks, Armbands, Swimsuits, Sprots bra, etc.
Production - this is done inner tube form, It is based on type of fabric /process.
Fine Printing | Brilliant Colours.
EPSON Gold generation print heads.
Direct printing on fabric.
- 1, 2, 4 Head combination.
- 4 / 6 / 8 Colors CMYK, CMYKOB, CMYKOBRLk.
- Fluorescent inks option.
- Wide Gamut.
- 30 to 100 GSM Paper.
- 1800 mm working width.
- Low ink consumption.
- Economical cost of production.
- EPSON Printheads, Variable drop.
- Neostampa ready.
Specifications:
| Models | Aura 8i | |
|---|---|---|
| Printing Head | Eight Epson Print Heads. Micro-Piezo | |
| Number of Nozzles | 3200 Each Head | |
| No of Colors | 8 Colors: Cyan, Magenta, Yellow, Black, Optional Spot Colors | |
| Height of Printing Head | Max 50mm adjustable | |
| Size of Ink Droplet | 1.5 – 21 PL | |
| Maximum Material Width | 1850mm | |
| Working Width | 1.80m | |
| Maximum Speed | 140 Sqm Per Hour (360×1200 DPI) | |
| 120 Sqm Per Hour (360×1800 DPI) | ||
| 75 Sqm Per Hour (720×1200 DPI) | ||
| Maximum Material Weight | 200 kgs | |
| Heater | Dryer Machine (hot air circulation) or Curing Machine (for Pigment/Disperse) | |
| Suitable Inks | Reactive / Acid / Pigment / Disperse Inks | |
| Ink Tank | 5 Litre ink pressure system | |
| RIP Sorftware | Neostampa | |
| Computer Specs required | Windows 10, CPU i5, RAM: 16GB | |
| Interface | Gigabit Ethernet | |
| Power Supply | AC220-240V 50-60HZ or 380V | |
| Power Consumption | Printer: 5 KW, Dryer:24 KW. Curing Heater: 24 KW | |
| Working Enviorment | Temperature: 15-28℃, Humidity: 40-80% | |
| Machine Dimenssion | 3100x1000x800 | |
| Packing Dimenssion | Printer: W4150*D2200 * H1650mm/Dryer:2350*2250*1550mm | |
| Machine Net Weight | Printer: 1500kg,dryer:800kg | |
