Main Features:
- Printing on Cuffs & Collars / Ribs
- 180 x 260 cm working width
- 4X Gold generation EPSON printheads
- 8 Colours
- Strong Rip
- Easy registration
- Robust designs
- Low Investment
- Low maintenance cost
- No Limitation of Colours
Specifications
| MODELS | AURA SMART 4SW |
| No of Heads | 4 |
| Head Type | LW007 |
| Ink Droplet Size | Variable Drop 3 to 21 pl |
| Working Size | 160 cm X 6 Mtr - Can be extended till 36 Mtr (in multiple of 3) |
| Flash Dryer | Optional (Recommended) |
| Media | Fabrics / Garments |
| Features | Sensor based registration Adjustable head height Suitable for high production and work with screen printing |
| Ink Droplet Size | Reactive / Acid |
| No Of Colors | 8 |
| Supply Mode | Continuous Ink Supply System |
| Operating System | Windows 10 64 Bit |
| RIP Software | Neostampa (Recommended) |
| Data Interface | Hi-USB 2.0/3.0 Mbps |
| Power | A/C 220 V 50/60 Hz |
| Environment | Temperature : 15 to 250C Humidity : 55 to 65 |
| Dimension (Machine) | 2750x6000x1200 mm (6 mtr) |
| Weight (Machine) | 380 Kg |
| Dimension (Packing) | 3150x500x630 mm 2860x630x720xmm |
| Weight (Packing) | 280 Kg 220 Kg |
The data here is subject to change without prior notice & is only for reference.
